1. Radiator: adopts the air-cooled plate-fin radiator to ensure that the system could operate in a maximum temperature allowed.
2. The main oil pump: adopts the German Hawe / Rexroth / Japanese Kawasaki series.
3. Lubrication system: adopts the automatic multi-point lubrication technology featuring one to one lubrication with better efficiency and the extending service life of wearing parts.
4. Power system: the power of motor series uses the well-known domestic and foreign brands: Yantai motor, Qingdao motor, Siemens Beide motor.
5. Diesel Series: power system employs the Lovol or Deutz diesel engine;
6. Electrical parts: the main electrical products adopts Schneider , LG products to the reliability of the electronic control system.
7. Hydraulic Hose Fittings: adopts the US Eaton products to ensure the safety of the hydraulic system, no leakage.
8. Large cylinder seals: Large cylinder seals adopts the US Parker products.
9. S valve: employing the manganese steel overall casting, the wearing surface adopts wear-resistant materials featuring the dual advantages of pressure and abrasion resistant.
10. Glasses plate cutting ring: glasses plates and cutting ring inlaid adopts the carbide hard to ensure a durable design.
11. Pistons: adopts the imported materials and precision machining, with excellent qualities: hydrolysis resistance, wear resistance and high temperature resistance.
|Max. Pump Times||Times/Min||24||20||22||22||23|
|Distribution Valve Type||S Tube Valve||S Tube Valve||S Tube Valve||S Tube Valve||S Tube Valve|
|Delivery Cylinder Type||Mm||Φ140×1200||Φ180×1300||Φ180×1300||Φ200×1650||Φ200×1650|
|Main Oil Pump||Mm||Φ80/55×1200||Φ100/70×1300||Φ110/70×1300||Φ125/80×1650||Φ125/Φ80×1650|
|Oil Tank Capacity||L||260||370||370||560||560|
|Delivery Pipe Inner Diameter||Mm||Φ125/Φ100||Φ125||Φ125||Φ125||Φ125|
|Hydraulic Oil-Way Type||Open||Open||Open||Open||Open|
|Max. Oil Pressure||MPa||26||31.5||31.5||31.5||31.5|
|Max. Oil Pressure For Mixing System||MPa||6-8||6-8||6-8||6-8||6-8|
|Max. Mixing Speed||R/Min||24||24||24||24||24|
|Maximum Aggregate Size||Mm||≤30（≤20）||Aggregate 40||Pebble 50, Aggregate 40||Pebble 50, Aggregate 40||Pebble 50, Aggregate 40|
